APPENDIX C. ENVIRONMENTAL TEST DESCRIPTIONS
ANNEX 2. DYNAMIC TESTS
TABLE C2-1. RESTRAINED CARGO TRANSPORT SHOCK LEVELS
Military Vehicle - Land Munitions
(800 km)
Half Sine Pulse
OR
Decaying Sinusoid
Frequency: 100 Hz
Duration: 0.37 s
Duration: 5 ms
(Number of Complete Cycles: 37)
Damping Factor: 3% of critical
Amplitude
Number of
Amplitude
Number of
(g pk)
Shocks
of First Peak
Repetitions
(g pk)
8.0
34
8.0
34
10.0
17
10.0
17
12.0
3
12.0
3
Military Vehicle Sea Munitions
(200 km)
Half Sine Pulse
OR
Decaying Sinusoid
Frequency: 100 Hz
Duration: 0.37 s
Duration: 5 ms
(Number of Complete Cycles: 37)
Damping Factor: 3% of critical
Amplitude
Number of
Amplitude
Number of
(g pk)
Shocks
of First Peak
Repetitions
(g pk)
8.0
9
8.0
9
10.0
5
10.0
5
12.0
1
12.0
1
NOTE: The number of shocks has been tailored from DEF STAN 00-35 Test M3 values to
arrive at the equivalent transport distance for each vehicle and munition type. All
shocks are to be applied in each sense of each orthogonal axis.
d. Test Temperature: Stabilize all cold munitions to -46 °C and all hot munitions to the
unpackaged SRE temperature prior to vibration testing. Test temperature is to be maintained
throughout vibration testing.
C.2-2.4 Tracked Vehicle Transportation Vibration.
Perform vibration testing in accordance with MIL-STD-810, Method 514 and ITOP 01-2-601
using the following test parameters:
a. Munition Configuration: This test should be conducted on individual munitions in the
military transport and tie-down configuration. For systems that may be transported in or out of
