APPENDIX C. ENVIRONMENTAL TEST DESCRIPTIONS
ANNEX 2. DYNAMIC TESTS
C.2-2 LOGISTIC LAND TRANSPORTATION DYNAMICS MILITARY.
For surface and underwater launched munitions, military land transportation dynamics addresses
the mechanical environments that may be encountered during military transportation by wheeled
and tracked vehicles. When testing for wheeled, there is effectively a vibration and a shock
element. Both the wheeled vehicle transportation vibration and retrained cargo shock tests must
be completed. Tracked vehicle transportation is applicable to land based munitions. All possible
vehicle types must be addressed in order to satisfy the S3 objectives for Logistic Land
Transportation Dynamics for Military Vehicles.
C.2-2.1 Military Wheeled Vehicle (Tactical/Composite Wheeled Vehicle) Transportation
Vibration.
Perform vibration testing in accordance with MIL-STD-810, Method 514 using the following test
parameters:
a. Munition Configuration: This test should be conducted on individual munitions in the
military transport and tie-down configuration. For systems that may be transported in or out of
the transport container, the test duration should be split with half of the test duration packaged in
the transport container and half of the test duration unpackaged.
b. Test Level: MIL-STD-810, Method 514, Figure 514.7C-4, `Category 4 Composite
wheeled vehicle vibration exposure'.
c.
Test Duration:
(1) Land Based Munitions: Test duration is equivalent to 8% of the distance specified
in AECTP 100, Annex E, Appendix 1 for transportation by `Land Military Vehicle' for a Land
Vehicle Mounted Missile, but no less than 800 km. Based on the current versions of AECTP 100
and MIL-STD-810, the test duration is 40 minutes/axis as calculated in Table A-2.
(2) Sea Based Munitions: Test duration is equivalent to 4% of the distance specified
in AECTP 100, Annex E, Appendix 1 for transportation by `Land Military Vehicle' for a Sea
Launched Missile, but no less than 200 km. Based on the current versions of AECTP 100 and
MIL-STD-810, the test duration is 10 minutes/axis as calculated in Table A-2.
d. Test Temperature: Temperature condition the test munitions prior to, and during
vibration testing. Stabilize all cold munitions to -46 °C, and all hot munitions to the packaged
SRE temperature.
