JOTP-011
5 December 2014
APPENDIX C. ENVIRONMENTAL TEST DESCRIPTIONS
ANNEX 2. DYNAMIC TESTS
d. Test Temperature: Temperature condition the test munitions prior to, and during
vibration testing. Stabilize all cold munitions to -46 °C, and all hot munitions to the packaged SRE
temperature.
C.2-5 TACTICAL COMBAT PLATFORM DYNAMICS.
Tactical Combat Platform Dynamics addresses the mechanical environments that may be
encountered during deployment on the tactical combat platform. It is recommended that actual
environments be measured and used to develop vibration and shock test criteria in accordance
with MIL-STD-810, Method 514, Annex F.
C.2-5.1 Land Based Munitions Tactical Dynamics.
C.2-5.1.1 Launch Vehicle Restrained Cargo Transport Vibration.
Perform vibration testing in accordance with MIL-STD-810, Method 514 using the following test
parameters:
a. Test Configuration: Attach the munition to the vibration exciter in the restrained cargo
transport configuration.
b. Test Level: Vibration test each munition in accordance with the vibration test schedule
representative of the munition location on the platform. Vibration specification development
guidance is provided in MIL-STD-810, Method 514, Annex F.
c. Test Duration: The required test duration is equivalent to 5000 km of launch vehicle
transport.
d. Test Temperature: Temperature condition the test munitions prior to, and during
vibration testing. Stabilize all cold munitions to -46 °C, and all hot munitions to the packaged
SRE temperature.
C.2-5.1.2 Launch Vehicle Restrained Cargo Transport Shock.
These shocks should be similar in content to the Restrained Cargo Transport Shock test of
paragraph C.2-2.2 and need not be repeated. Use measured data with the munition on the tactical
platform to verify the levels.
C.2-5.1.3 Tactical Launcher Vibration.
Perform vibration testing in accordance with MIL-STD-810, Method 514 using the following test
parameters:
C.2-10
