JOTP-011
5 December 2014
APPENDIX C. ENVIRONMENTAL TEST DESCRIPTIONS
ANNEX 2. DYNAMIC TESTS
determined to be sufficiently benign compared to other dynamic environments.
c.
Number of Shocks: The required number of shocks is determined by the LCEP.
d. Test Temperature: Temperature condition the test munitions prior to, and during shock
testing. Stabilize all cold munitions to -46 °C, and all hot munitions to the SRE temperature.
C.2-5.2 Sea Based Munitions Tactical Dynamics.
C.2-5.2.1 Tactical Ship and Underwater Launch Configuration Vibration.
Perform vibration testing in accordance with MIL-STD-810, Method 528 using the following test
parameters:
a. Munition Configuration: Attach the munition to the vibration exciter in all relevant
tactical launcher transport or deployment configurations.
b.
Test Level: MIL-STD-810, Method 528.
c.
Test Duration: The test should be conducted for the default duration of one hour per
axis.
d. Test Temperature: Temperature condition the test munitions prior to, and during
vibration testing. Stabilize all cold munitions to -34 °C, and all hot munitions to the unpackaged
SRE. Test underwater launched munitions at standard ambient conditions.
C.2-5.2.2 Tactical Ship Adjacent Munition Firing Shocks.
Perform shock testing in accordance with MIL-STD-810, Method 516 using the following test
parameters:
a. Test Configuration:
Attach the munition to the shock exciter in the launch
configuration.
b. Test Level: Shock test each munition to a tailored shock response spectrum (SRS)
representative of the launcher location on the platform(s). SRS specification development
guidance is provided in MIL-STD-810, Method 514, Annex F. This test may be eliminated if
determined to be sufficiently benign compared to other dynamic environments.
c.
Number of Shocks: The required number of shocks is determined by the LCEP.
d. Test Temperature: Temperature condition the test munitions prior to, and during shock
testing. Stabilize all cold munitions to -34 °C, and all hot munitions to the SRE temperature. Test
C.2-12
